The DICOM Labels feature provides visual indicators on top of the MedDream viewer interface that enhance usability by clarifying or adding relevant information to the images being reviewed.
How to Enable
Project Level (Project Edit Permission Required)
-
Navigate to your project's dashboard
-
Click on the Edit icon located at the top right portion of the screen
-
Click on Show Advanced settings
-
Locate the Project Labels section
-
Click on Add
-
Type your label in the item textbox
-
Click Save
How to enable DICOM Labels for your project
How to Apply DICOM Labels to Studies
Data Browser Module (Project Edit Permission Required)
To make the labels visible on the Viewer:
-
Navigate to an event configured with the Databrowser module, such as e.g. a review event
-
Locate the study you want to label
-
Expand the study to view the series
-
Click on the round "+" button next to the desired series. A modal will appear
-
Select one or more labels from the list of labels previously defined at the project level
- Click on the Submit button
Applying DICOM labels to series and displaying the labels in the DICOM viewer
Once a label is added to a study through the Data Browser, it will be visible as a visual tag in the Viewer during image review.
Note: If your newly added label is not being displayed on the viewer, try reloading the page with the Databrowser and relaunching the viewer after reload.
